What is X-frame

X-frame is the perfect solution for machine frames that must meet individual requirements. We have been planning, designing and assembling machine frames from the häwa-designed and patented X-frame modular system since 2008.

Over the years, we have developed unparalleled manufacturing expertise. The continuous integration of designs that have proven themselves in practical customer applications has allowed us to develop X-frame, a machine frame that can be expanded as required and customized to meet individual customer requirements. Our designers draw on this wealth of experience to develop the right solution for every new challenge. The significantly lower design effort required saves us valuable time in project planning and design, thereby noticeably reducing costs. The modular design of X-frame offers the best possible convenience and maximum flexibility when it comes to machine frames. A modular system with almost no limits. X-frame is constantly being optimized and further developed. For customized solutions for a wide range of product ranges, as well as for one-off and customer-specific features.

Rotate, turn, zoom and open our X-frame machine frame.

The X-frame struts

X-frame struts are available for various loads. The horizontal and vertical frame struts are manufactured in different strengths. Thanks to their modular design, they can be easily connected to one another. The cable routing runs in the horizontal and vertical struts (for the light struts, access to the cable area is on the inside of the system). Custom dimensions can be realized at any time. This means that we have the perfect strut in every area of the frame and can avoid oversizing.

With their smaller cross-section, the specially developed X-frame Light struts allow a maximum access width on narrow systems.

X-frame braces are used for systems with weight loads of up to 1 ton. A special feature here is our vertical 90° corner braces. They are folded 13 times for maximum load.

We use our Pro-X struts made of 3 mm sheet steel to build machine frames for higher loads.

We have developed special robot struts for highly dynamic applications. With wall thicknesses of up to 13 mm, these can also withstand high torques and guarantee a high level of picking accuracy. We provide FEM calculations as proof of the quality of the systems.

For special requirements in terms of precision in an X-frame machine, häwa manufactures welding frames with the highest precision. Tube cross sections are adjusted and the frames can be annealed to prevent subsequent deformation. Milling in flat bed or portal milling machines and coating with the desired surface finish ensure a perfect result.

Rotate, turn and zoom in on our X-frame struts.

UL-certified machine frames

UL is one of the most important independent organizations worldwide for the testing and certification of materials, components and end products in the area of product safety. All products exported to the USA and Canada, especially machine frames, should be certified. The certification process according to North American standards for electro-technical products simplifies market entry.

The patented X-frame machine frames are available with UL certification, simplifying acceptance and start-up. Customers in the USA and Canada can rest assured that they are not taking any risks with häwa products.

[Translate to English:] Erdungsband am häwa Schaltschrank

[Translate to English:] FEM-Berechnung häwa

FEM calculation

We perform FEM calculations for systems with high static and dynamic requirements.

The finite element method (FEM) is a numerical method that visually represents all mechanical properties. This can be used to verify the stability, picking accuracy and quality of the system. Thanks to FEM calculations, targeted optimization measures can be taken and designs can be adapted at an early stage to prevent time-consuming and costly rework.

X-frame machine frames by häwa – your advantages

X-frame – the answer to all your questions.

Complex requirements demand intelligent solutions. No two machine cells or applications are the same. They all have one thing in common: they must be designed freely and individually and grow with the requirements. We at häwa have the answer: the modular design of the X-frame offers the best possible convenience and maximum flexibility when it comes to machine frames. A modular system that knows (almost) no limits. And the best part: the X-frame modular system is constantly being optimized and further developed. For customized solutions for a wide range of product ranges, as well as for one-off and customer-specific requirements.

X-frame – because functional can also be beautiful.

The unconditional functionality of products and solutions is of the utmost importance at häwa. The goal of new development is to achieve the highest level of practicality through design, while maintaining the highest technical standards. Design is the means by which we visualize quality, modernity, reliability, serviceability and efficiency. The X-frame concept is a prime example. Color The product family is characterized by an ergonomic design with clean lines, individual color schemes according to customer requirements, and powder-coated or stainless steel surfaces. This makes each machine frame unique.

X-frame is the perfect solution for machine frames that fulfill individual requirements.

Since 2008, we have been planning, designing and assembling machine frames based on the häwa patented X-frame modular system. The European patent protects our solution at the international level under patent and trademark law. This means that no other manufacturer is allowed to copy the solutions protected by the patent. This makes X-frame unique on the market with its integrated cable routing in the machine frame struts, access doors to these areas, and integrated control cabinets. This patent guarantees our customers that their machine frame from häwa is always an original and is as cutting edge in its functionality as it is in its quality.

X-frame – because it's your money and your time.

Time is money! You should not have to spend your valuable time constructing and assembling machine frames. That is what we at häwa are here for. While you take care of your core business, you can rest assured that the realization of your individual solution is in the best of hands. Since the frames are divided into modular, coordinated assemblies that can be exchanged and mounted with each other, valuable synergies and The integration of switch cabinets is possible at all levels, and cable ducts are available. häwa passes these advantages directly on to the customer in the form of an attractive price-performance ratio.

X-frame – because there is no compromise when it comes to safety.

We at häwa make no compromises when it comes to product safety. Safety begins with the planning of an X-frame machine frame. The compact solution in a modular system reduces space requirements and construction costs, and thus simplifies engineering and commissioning. It is stable and has above-average load capacity. And it is characterized by extensive options: every desired safety system can be integrated to secure the access areas. Effective laser protection, earthing bolts on all standard components, light-tight construction as protection against harmful UV light, conductive surfaces – an X-frame machine frame meets all requirements.
